Two-channel BUS09 is available Surface Mounted, Hanging, or Wall-Mounted. Like all BusRun, it falls under Article 368 of the NEC, providing it with distinct advantages over track. It is available with up to 2-circuits per channel, for up to four channels, and has a capacity of up to 60 Amps.
Specifications
120, 240 and 277 Volts
2-4 Circuits (120/240 V)
2-circuits (277 Volts)
16, 20, 30 and 60 Amps
Dimensions
2-1/16” W x 2-3/8″ H
53mm W x 61mm H
Mounting
Surface-Mounted
Finish
White, Black, Brushed Aluminum, or Custom
Loading
Max 100 lb [45.4kg] between support points
